| Charging mode parameters | |
| Rated output power | 80kW |
| Grid side voltage | 380Vac±15%(Three phase) |
| Grid frequency | 50Hz±5Hz |
| DC side output voltage | 200~750Vdc |
| Constant power range | 400~750Vdc |
| DC side output current | Maximum 200A |
| Discharge mode parameters | |
| Rated output power | 80kW (input: 400~750Vdc) |
| DC side input voltage | 200~750Vdc |
| Grid side voltage | 380Vac(Three phase) |
| Grid frequency | 50Hz±5Hz |
| System parameter | |
| THDI | <5%(Full load) |
| Power factor | ±-0.99(Full load) |
| Productiveness | ≥95%(Full load) |
| Wiring Mode | 3P3W |
| Noise | ≤65 dB |
| Cooling method | Forced air cooling |
| Power distribution | support |
| Number of charging guns | Single gun |
| Protection level | IP54 |
| communication interface | Ethernet, 4G |
| Display | 7-inch touch screen |
| Charger Cable | 5m |
| DC output characteristics | |
| Output voltage range | 200 V～750 V |
| Output current range | Maximum 200A |
| Output voltage measurement error | Not more than ± 0.1% (Steady state, input voltage AC 323 V to 456 V, output voltage 200 V to 750 V, output current 0 to rated current value) |
| Output current measurement error | Not more than ± 0.1% (steady current state, input voltage AC 323 V to 456 V, output voltage 200 V to 750 V, output current 20% of rated current to rated current value) |
| Voltage ripple factor | Not more than 1% (in stable state, the input voltage is AC 323 V to 456 V, the output voltage is 200 V to 750 V, and the output current is 0 to the rated current value) |
| Output voltage setting error | Not more than ± 0.5% (stabilized state, output voltage 200 V to 750 V) |
| Output current setting error | Not exceeding ± 0.3 A (set output DC current ＜ 30 A); |
| Not more than ± 1% (steady current state, set output DC current ≥ 30 A) | |
| Temperature measurement error | ±0.5℃ |
| Time measurement error | ±0.1s |
| Insulation accuracy | ±5% |
| Protection features: input overvoltage and undervoltage protection, input overcurrent protection, output overvoltage and undervoltage protection, overtemperature protection, etc | |
