| Product model | JWE-D120K-1000V-OHB | JWE-D150K-1000V-OHB | JWE-D180K-1000V-OHB |
| Installation method | Console mode | Console mode | Console mode |
| Rated power | 120 kW | 150 kW | 180 kW |
| Technical indicators | AC input voltage: three-phase five-wire AC 380V ± 15% | ||
| Power factor correction is integrated inside the charger to minimize harmonic pollution to the power grid | |||
| DC output voltage:200-1000V | |||
| Maximum output current of single gun: 250A | |||
| Power factor: above half load, ＞ 0.98; Load 20% - 50%, ＞ 0.95 | |||
| System efficiency: Full load ＞ 95%; More than half a load ＞ 93%; | |||
| Using high-frequency zero voltage soft switching technology, the reliability and efficiency of operation are much higher than those of hard switching circuits. | |||
| Steady current accuracy: ＜± 1% | |||
| Voltage stabilization accuracy: ＜ ± 0.5% | |||
| Output voltage ripple coefficient: ＜ ± 1% | |||
| Harmonic current:<5% | |||
| Standby power consumption: ≤ 100W | |||
| Zero power consumption in standby state of primary circuit | |||
| Protection grade: IP54 | |||
| Protection features: multiple protection functions such as input undervoltage, input overvoltage, output short circuit, output overvoltage, battery reverse connection, insulation detection, communication failure, etc. | |||
